GPS Trackers
Omnicomm’s range of GPS Trackers (vehicle trackers) deliver a consistently high performance, whatever the environment. They are versatile, reliable and efficient. Our GPS Trackers can be installed in a wide variety of vehicles. They are connected to a range of sensors and to an on-board computer. This data is read and transmitted to the fleet management system.
All Omnicomm GPS Trackers, are compatible with most third-party monitoring systems, sensors and peripherals.
Omnicomm PROFI 3.0 GPS tracker is a device for collecting information about the condition of the vehicle and transmitting data to the Omnicomm Online cloud service or third-party software via GSM networks
This feature-packed GPS Tracker is built for medium and heavy trucks operating in complex projects and in highly demanding situations. It has an IP54 protection rating. The standard version supports 2G, the second version is equipped with WiFI for areas without GSM coverage and the third version supports 3G. All three versions are extremely well protected and completely tamper-proof.
| Location Technology | GPS/GLONASS, 32 channels |
| Location Accuracy | 3m |
| Data Support | GSM 850/900/1800/1900 MHz, GPRS, SMS |
| SIM capability | 1 SIM card + 1 SIM chip* |
| Interfaces | CAN interface (J1939, J1708, FMS), 2xRS-485, 1xRS-232, USB, 1-wire |
| Operating Voltage | 8…65 |
| Backup battery capacity, MA-h | 1400, Li-pol |
| Operating temperature range, C | -40...+85 °С |
| Ingress Protection Rating | IP52 |
| Dimensions | 100 x 137 x 38 mm |
| Antenna | External, SMA socket |
| Inputs and Outputs | 6 x Universal Inputs, 2 x Discreet Outputs, Separated: Ignition key input, Panic button input, RPM input, Dispatcher button (GSM) |
| The volume of non-volatile memory, events | 150 000 |
Omnicomm Optim 3.0 GPS tracker is a device for collecting information about the condition of the vehicle and transmitting data to the Omnicomm Online cloud service or third-party software via GSM networks
The Omnicomm Optim offers a rich set of features including two external antenna (forGPS/GLONASS and GSM) for extra reliability in areas with limited mobile coverage. It is
designed for use in medium and heavy-duty vehicles and has an IP52 protection rating.
It supports two SIM cards out of the box — one can be used in the home region and the
other while roaming.
| Location Technology | GPS/GLONASS, 32 channels |
| Location Accuracy | 3m |
| Data Support | GSM 850/900/1800/1900 MHz, GPRS, SMS |
| SIM capability | 2 SIM cards or 1 SIM card + 1 SIM chip* |
| Interfaces | CAN interface (J1939, J1708, FMS), 2xRS-485, 1xRS-232, USB, 1-wire |
| Operating Voltage | 8…65 |
| Backup battery capacity, MA-h | 1400, Li-pol |
| Operating temperature range, C | -40...+85 °С |
| Ingress Protection Rating | IP52 (upon using protection plate and sealing) |
| Dimensions | 101 x 90 x 32 mm |
| Antenna | External, SMA socket |
| Inputs and Outputs | 4 x Universal Inputs, 2 x Discreet Outputs, Separated: Ignition key input, Panic button input, RPM input, Dispatcher button (GSM) |
| The volume of non-volatile memory, events | 150 000 |
Omnicomm Profi 3.0 Wi-Fi GPS tracker is a device for collecting information about the condition of the vehicle and transmitting data to the Omnicomm Online cloud service or third-party software via GSM or Wi-Fi networks
This feature-packed GPS Tracker is built for medium and heavy trucks operating in complex projects and in highly demanding situations. It has an IP54 protection rating and equipped with WiFi for areas without GSM coverage It is extremely well protected and completely tamper-proof as the other versions of the product.
On-board equipment for retrieving data from Omnicomm Profi Wi-Fi terminals, storing it in non-volatile memory and transmitting data to a communication server when connected to the Internet.
OMNICOMM PORT is a comprehensive solution designed to streamline data collection from vehicles operating in areas with limited or no cellular connectivity. Whether it's a quarry, mountainous terrain, remote highway sections, tunnel construction, or underground facilities, OMNICOMM PORT has you covered.
In GSM-free zones, all equipment is equipped with a PROFI WiFi terminal, storing data in its internal memory. Once within GSM/WiFi coverage, the data is seamlessly transmitted to OMNICOMM PORT installed on your vehicle (fuel tanker, technical vehicle, crew bus, etc.). From there, it's relayed to OMNICOMM ONLINE for comprehensive data management.
